Home > Products > Outdoor Bike Rack > Vertical Bike Racks > Bicycle Shelter with Semi-Vert.....
Bicycle Shelter with Semi-Vertical Racks/Bicycle StorageBicycle Shelter with Semi-Vertical Racks/Bicycle StorageBicycle Shelter with Semi-Vertical Racks/Bicycle Storage

Bicycle Shelter with Semi-Vertical Racks/Bicycle Storage

  • Specifications
  • Model Number : PV-L
  • Type: Bike parking and storage
  • Color:Black
  • Style : both indoors and outside
  • Material : carbon steel
  • Loading: 2-10 bikes (According to customer need)
  • Size :Height 1463mm, Depth 1114mm
  • Finish: hot-galvanized


Product Name

 Bicycle Shelter with Semi-Vertical Racks/Bicycle Storage


 carbon steel


Height 1463mm, Depth 1114mm


 2-10 bikes(According to customer need)




 Normal packing





Features & Benefits

The Semi Vertical Bike Rack is designed to maximise the use of space.

  • Can be manufactured for any number of bikes
  • Galvanised steel tube, section, bar and plate
  • Height 1463mm, Depth 1114mm
  • 305mm centres
  • Maximum tyre width 56mm
  • For bolting down only (pack of bolts available extra)
  • Price is Per Space
  • Optional locking loop available to increase security by allowing the bike frame to be locked to the rack with a standard d-lock.

  • How much space do I need?

To be comfortable, we advise at least a 1500mm depth and a width of:

  • 2 bikes - 610mm
  • 3 bikes - 915mm
  • 4 bikes - 1220mm
  • 5 bikes - 1525mm
  • 6 bikes - 1830mm
  • 7 bikes - 2135mm
  • 8 bikes - 2440mm
  • 9 bikes - 2745mm
  • 10 bikes - 3050mm



Lifetime Warranty
When we say "We bring the power of cycling to life, we mean it". Talk's cheap. That's why you'll see lifetime warranties on our Suzhou Pioneer racks. Not three years, not five, but for as long as the original buyer owns it. Because we firmly believe that cycling is a lifetime sport. So why settle for anything less from the equipment that helps you enjoy it.

Official Warranty Term

Suzhou Pioneer vehicle Co.,Ltd, we promise our product to the original consumer to be free from defects materials and workmanship. Please retain your sales slip for your records as proof of purchase will be required.
